Bar Cutting Machine

Our highly effective Bar Cutting Machines are equipped with the latest technology, which makes them very accurate in their cutting. The Bar Cutting Machine is designed with strong and sharp blades, which are highly durable and ensure complete safety. Our Bar Cutting Machine is capable of performing various operations at the same time. Cutsomers can avail from us Bar Cutting Machine at prevailing industrial rates.

Features :

• Compact & Highly Reliable Design
• Easy Material Handling
• Durable
• High strength
• Easy to use

Benefits :

• More productive than manual work
• Less labor force and construction cost
• Continuous operation
• Excellent operation

» Specifications

Model	Tensile Strength	No. of Rods / Cutting Dia			App. Dimensions in cm	Motor H.P	App. Weight (Kg)
		1	2	3
REL - 30	45 kg/sq.mm	28	20	16	58 x 80 x 80	3	250
	65 kg/sq.mm	25	16	12
REL - 35	45 kg/sq.mm	32	22	18	58 x 92 x 82	5	355
	65 kg/sq.mm	28	18	16
REL - 40	45 kg/sq.mm	40	25	20	62 x 92 x 83	7.5	385
